2.0mm Single Row Pin Header Connector Right Angle SMT Type
| Basic Parameters | |||
|---|---|---|---|
| Part Number | 322XXXZXX1XXXXXX | ||
| Type | Pin Header | ||
| Pitch | 2.0mm | ||
| Rated Current | 2.0A | ||
| Withstand Voltage | 500V/AC/1min | ||
| Contact Resistance | ＜30.0mΩ | ||
| Insulation Resistance | ≥1000MΩ | ||
| Operating Temperature | -40°C~105°C | ||
| Contact Material | Copper Alloy | ||
| Insulator Material | PA6T | ||
